SR Series
- Sizes: ½” – 1”
- Pressure: 1/2″ – 1″ @ 2,000 PSI NSCWP
- Specifications & Compliance
- Design: ASME BPVC VIII-1
- Inspection & Testing: API 598
- NACE MR 0175/ISO 15156-1 Compliant
- Fire Safe Design: API 607 (L.E.)
- Socket Weld Ends per ASME B16.11 (Available upon request)
- Threaded Ends per ASME B1.20.1
- Port: Full Port
- Body: WCB, LCC, CF8M
- Ball: ASTM A182 F316 Stainless Steel
- Stem: ASTM A564 17-4PH Stainless Steel, Blow-out Proof Design
- Additional Features: 2-piece Seal-Welded Body, NACE Compliant, Floating Ball, Threaded FNPT Ends, Spring Return & Dual Stem sealing design
